The Lambda X series is a fully modular and highly flexible machine platform for semi-automatic or fully-automatic processing of complex connector systems.
Finance available on this product subject to credit approval
Lambda X Series
Maximum productivity with the innovative transfer system
Freely movable workpiece carriers minimize production space and cycle times, as the modules can be lined up without unnecessary free space.
Future-oriented investment
Thanks to the modular concept, it is possible to individually enhance the degree of automation during the ramp-up process at the customer’s request or to expand it with functions.
| Approximate energy consumption with 3’500’000 wires | 31600 kWh |
| Cable length (uncoiled) | 5000mm |
| Wire length coiled max. | 15000mm |
| Wire outer diameter max. | 6mm |
| Shortest wire length for one-sided processing | 120mm |
| Shortest wire length for two-sided processing | 550mm |
| Electrical connection | 3 × 400VAC±10%, 50/60Hz |
| Current | 32A, typeD |
| Compressed-air connection | 7-10 bar |
| Air consumption | ~460 l/min |
| Weight | ca. 5000 kg |
| Width | 11600mm |
| Length | 4550mm |
| Height (with tower light) | 2300mm |
| Noise level | ≤ 80 dBA |
| Ambient temperature min. | 15°C |
| Ambient temperature max. | 40°C |
| Cycle time | >4.5 sec |
| Connector systems | Coax, mini Coax, Automotive Ethernet UTP, and STP |
| Maximum yearly output | 4270000 |
| Transfer system | Circumferential linear magnetic transfer |
| Processing outside the specifications | Processing outside the specifications upon request. |
